Electric hoist for automotive engine removal

Designed for the Demands of the Garage:

Forget struggling with cumbersome chain falls or risking damage with inadequate lifting gear. The Weihua Electric Hoist for automotive engine removal provides a superior, wydajny, and safe method to extract and install engines in cars, trucks, SUVs, and light commercial vehicles. It transforms a potentially hazardous and time-consuming job into a streamlined operation.

Key Features & Benefits for Engine Removal

• 1. Precise Variable Speed Control: Dual-speed operation (standard on most models) allows for smooth, millimeter-perfect maneuvering. Gently lift the engine clear of mounts and carefully navigate it out of the tight confines of the engine bay without bumps or scrapes. Slow speeds are crucial for delicate alignment during reinstallation.

• 2. Robust Lifting Capacity: Engineered to handle typical automotive engine weights (commonly 300kg to 2000kg / 660 lbs to 4400 funty), Weihua hoists offer capacities perfectly suited for the task. Select the model matching your common workload (NP., CXLT, CXT, or CD1 series).

• 3. Wytrzymała konstrukcja & Trwałość: Built with high-tensile strength steel, hardened gears, and abrasion-resistant wire rope or high-strength load chain. Resists the greasy, demanding environment of automotive workshops, ensuring longevity and reliable performance.

• 4. Kompaktowa konstrukcja & Low Headroom Electric Chain Hoist: Many Weihua hoist models feature a low headroom design, maximizing usable lifting height – a critical factor when working under vehicle hoists or in garages with limited ceiling clearance.

• 5. Enhanced Safety Features: Engine removal involves significant risk. Weihua hoists incorporate vital safety elements:

  • Zabezpieczenie przed przeciążeniem: Prevents hoist operation beyond its rated capacity, protecting both personnel and the engine/vehicle.
  • Fail-Safe Braking System: Dual braking (mechanical and electromagnetic) ensures the load is held securely, even during power loss.
  • Zatrzymanie awaryjne: Immediate cut-off for critical situations.
  • Wyłączniki krańcowe: Automatic cut-off at upper and lower travel limits prevents over-hoisting or slack rope/chain.

• 6. Płynna praca & Reduced Effort: Electric power eliminates strenuous manual pulling. Operators control lifts effortlessly via pendant control, significantly reducing fatigue and improving ergonomics.

• 7. Zgodność: Designed to integrate seamlessly with common garage lifting structures like I-beam trolleys (manual or motorized) or gantry crane systems, providing flexible movement over the vehicle.

Kluczowe parametry techniczne: Weihua Electric Hoists for Engine Removal

(Standard Models | Customizable Options Available)

Parametr	CXLT Series (Chain Hoist)	CXT Series (Wire Rope Hoist)	CD1 Series (Chain Hoist)
Pojemność podnoszenia	0.25T, 0.5T, 1T, 2T, 3T, 5T	0.5T, 1T, 2T, 3T, 5T, 10T	0.25T, 0.5T, 1T, 2T, 3T
Prędkość podnoszenia	Dual-Speed: 3/0.5 m/mój (Standard) 8/1.3 m/mój (Fakultatywny)	Dual-Speed: 8/1.3 m/mój (Standard) 13/2 m/mój (Fakultatywny)	Single/Dual-Speed: 3/0.5 m/mój
Wysokość podnoszenia	3M (Standard) Up to 30m (Custom)	6M (Standard) Up to 50m (Custom)	3M (Standard) Up to 20m (Custom)
Headroom	Ultra-Low: 550–900mm	Moderate: 700–1,200mm	Low: 600–950mm
Zasilanie	230V/1ph/50Hz 400V/3ph/50Hz	230V/1ph/50Hz 400V/3ph/50Hz	230V/1ph/50Hz 400V/3ph/50Hz
Klasa obowiązków	MES 1 w nocy, 2M (Medium Duty)	MES 1 w nocy, 2M (Medium Duty)	MES 1 w nocy (Light-Medium Duty)
System sterowania	IP54 Pendant Zatrzymanie awaryjne	IP54 Pendant Zatrzymanie awaryjne	IP54 Pendant Zatrzymanie awaryjne
Ocena ochrony	IP54 / IP55 (Dust/Waterproof)	IP54 / IP55	IP54
Typ wózka	Podręcznik / Motorized (I-Beam)	Podręcznik / Motorized (I-Beam)	Podręcznik / Motorized (I-Beam)
Trolley Travel	Podręcznik: 1-5 t capacity Motorized: 4-20 m/mój	Podręcznik: 1-5 t capacity Motorized: 8-20 m/mój	Podręcznik: 1-3 t capacity

Critical Specs for Engine Removal Context

• 1. Capacity Range:

  • Most automotive engines: 0.5–2 tons (NP., sedan: 0.5T, SUV/truck: 1–2T).
  • Wytrzymałe (diesel trucks): 3–5 tons (CXLT/CXT recommended).

• 2. Headroom Advantage:

  • CXLT series excels in low-ceiling garages (headroom ≤ 900mm).

• 3. Speed Precision:

  • Dual-speed control (NP., 8 m/min for fast positioning + 0.5 m/min for millimeter-accurate alignment).

• 4. Safety Compliance:

  • Overload cutoff (110% pojemność znamionowa).

  • Double electromagnetic brakes (holds load during power loss).

  • Upper/lower limit switches (auto-stop).

• 5. Environment Resilience:

  • IP54/IP55 rating resists oil, pył, and workshop humidity.

Typical Workshop Configuration

• 1. Hoist: Weihua CXLT 1T (Chain) or CXT 2T ( Elektryczny wciągnik linowy).
• 2. Wózek z podnośnikiem elektrycznym: Motorized (8 m/min travel) for smooth engine maneuvering.
• 3. Wysokość podnoszenia: 4–6m (standard workshop gantry/crane height).
• 4. Woltaż: 230V single-phase (compatible with garage outlets).

Ideal Weihua Models for Automotive Engine Removal

• Weihua CXLT Series Electric Chain Hoist: Excellent for rugged environments. Offers durability, lower headroom, and smooth chain operation. Ideal for capacities up to 5 mnóstwo.

• Weihua CXT Series Electric Wire Rope Hoist: Provides higher lifting speeds and heights. Features precise control and robust construction. Well-suited for capacities often needed in larger workshops (NP., 1 tona, 2 tona).

• Weihua CD1 Series Electric Chain Hoist: A reliable and cost-effective option for lighter-duty or less frequent engine work. Known for its simplicity and durability.

Why Choose Weihua for Your Engine Hoisting Needs?

• 1. Global Reliability: Weihua is a major manufacturer with a proven track record for quality and durability.
• 2. Engineered for Safety: Comprehensive safety features protect your technicians and valuable assets.
• 3. Precyzja & Kontrola: Essential for the delicate task of removing and installing engines without damage.
• 4. Trwałość: Built to withstand the harsh workshop environment.
• 5. Efektywność: Dramatically speeds up engine removal and installation jobs.
• 6. Wide Model Range: Find the perfect capacity and features for your specific automotive workshop requirements.

Invest in a Weihua Electric Hoist specifically chosen for automotive engine removal. Experience the difference that power, precyzja, kontrola, and unwavering safety make when handling the heart of the vehicle. Contact your local Weihua distributor or visit the official Weihua website to explore the full range and find the ideal solution for your automotive repair or engine rebuilding business.
