1 Тонна електричний ланцюг підйомника

З 1 tonne electric chain hoist is ideal for small and medium-sized lifting tasks due to its compact design, high cost performance and flexible maneuverability. Whether it is precision operations on the production line or heavy-duty handling outdoors, we can provide safe and efficient solutions. When purchasing, you need to match parameters according to actual working conditions, and give priority to brand products that have passed CE and ISO certifications.

Features of 1 тонна електричний ланцюг підйомника

• 1. Efficient and labor-saving: Compared with manual hoists, electric drive greatly improves work efficiency and reduces labor intensity.
• 2. Точний контроль: The lifting/lowering speed can be fine-tuned, suitable for precision assembly or positioning scenarios.
• 3. Безпечний і надійний: The overload protection device automatically cuts off the power supply to prevent overload damage. Dual brake system (electromagnetic brake + mechanical brake), automatically locks when power is off. Upper and lower limit switches to prevent excessive chain retraction.
• 4. Сильна довговічність: IP54 protection level (dustproof and waterproof), suitable for harsh industrial environments.
• 5. Гнучка установка: Електричний підйомник can be fixed on the I-beam track or used with a trolley to achieve lateral movement (an optional running trolley is required).

1 tonne electric chain hoist technical parameters

Project	Параметр
Оцінене навантаження	1 тонна (1000 кг)
Висота підйому	Стандартний 3 метрів (можна налаштувати 20 метрів)
Збільшити швидкість	Одна швидкість: about 8 м/мій; double speed: 4/8 м/мій
Напруга живлення	220V/380vac, 50/60Гц
Потужність двигуна	0.8-1.5 kw (в залежності від моделі)
Chain diameter	6-8 мм (alloy steel material)
Робоча система	S3 40% (intermittent work system)
Net weight	Про 50-80 кг (depending on configuration)

1 tonne electric chain hoist application

• Manufacturing industry: machine tool component installation, production line material lifting.
• Warehousing and logistics: завантаження та розвантаження контейнерів, pallet cargo lifting.
• Automobile maintenance: engine lifting, body moving.
• Будівництво: temporary lifting of small building materials and pipeline equipment.
• Energy industry: equipment maintenance, partial handling of generator sets.

1 tonne electric chain hoist selection and purchase suggestions

• Environmental adaptation: Humid/high temperature environments require a higher protection level (наприклад IP65).
• Frequency of use: For high-frequency operations, it is recommended to choose industrial-grade models (such as S4 working system).
• Power Matching: Verify site voltage and equipment compatibility (three-phase or single-phase).
• Extended functions: If lateral movement is required, an electric running trolley is required.
