2000 Pound Electric Hoist​

Weihha 2000 pound electric hoist combines Weihua’s years of accumulated professional technology and strict quality control system, and is an ideal choice for workshops, Kho, repair shops, production lines and various light industrial applications. As one of the world’s leading crane manufacturers, Weihua Group is well-known in the industry for its excellent craftsmanship, reliable performance and advanced technology.

Six core advantages of the 2000 pound electric hoist

1. Powerful and Reliable: Adopts high-quality motor and optimized gear drive system to provide stable and powerful lifting power, ensuring efficient and smooth operation under 2000 lbs load.

2. Safety first: Multiple safety protection devices as standard:

   • Dual brake system: Double protection of electromagnetic disk brake (main brake) and mechanical load brake (auxiliary brake) to ensure safe braking of load in power outage or emergency.

   • Bảo vệ quá tải: Các 2000 pound electric hoist has a built-in overload limiter, which automatically cuts off the lifting circuit when the load exceeds the rated value (usually 110%) to protect the safety of equipment and personnel.

   • Upper and lower limit switches: Precisely control the lifting stroke of the hoist to prevent it from hitting the top or being lowered too much.

   • Thermal Protection: The motor has built-in thermal protection to prevent overheating damage due to overload or frequent use.

3. Efficient and durable:

   • Optimized gearbox: Precision machined hardened gears, heat treated and ground, have high transmission efficiency, low noise, low wear and long life.

   • Solid Structure: The key components of the 2000 pound electric hoist are made of high-strength alloy steel, the overall structure is compact and solid, and durable.

   • High-quality wire rope: Standard high-strength, chống mòn, anti-rotation wire rope ensures a safe and reliable lifting process.

4. Easy to operate:

   • Lightweight design: The main unit has a reasonable weight, making it easy to install and carry.

   • Ergonomic hanging button station: Comfortable operating handle design, clear button layout, clear UP and DOWN directions, intuitive and easy operation. Optional cable length (usually standard configuration is 10-15 bàn chân).

   • Smooth starting and braking: Optimized control circuit ensures smooth starting and stopping of lifting and lowering, reducing load shaking.

5. Flexible application:

   • Low Headroom Design: Some models of 2000 pound electric hoists adopt low headroom design to maximize the use of vertical space, especially suitable for places with height restrictions.

   • Multiple mounting options: Can be easily mounted on an I-beam (standard trolley or optional trolley), KBK light rail or other supporting structures.

   • Optional voltage: Provide a variety of voltage specifications (such as 120V/1ph/60Hz, 230V/1ph/60Hz, 208-230V/3ph/60Hz, vân vân. commonly used in North America) to meet the power supply needs of different locations.

6. Easy maintenance: Weihua electric hoist has a modular design, and key components are easy to inspect and maintain, reducing subsequent maintenance costs and time.

Application scenarios of Weihua 2000 pound electric hoist

• 1. Automobile repair workshop (engine and gearbox disassembly and assembly)

• 2. Small and medium-sized machinery manufacturing and assembly lines

• 3. Warehouse Material Handling

• 4. Equipment repair and maintenance

• 5. Installation of small components at construction sites

• 6. Laboratory equipment hoisting

• 7. Stage scenery and lighting equipment installation

• Anywhere loads up to 907 kg (2000 lbs) need to be lifted safely and reliably.

Weihha 2000 lbs Electric Hoist Key Parameters

Parameters	Parameter Value
Rated lifting capacity	2000 lbs (907 kg)
Standard lifting height	10 ft, 15 ft, 20 ft, 30 ft (3m, 4.5m, 6m, 9m) or customized
Tốc độ nâng	Single speed: Approx. 6-8 ft/min (1.8-2.4 m/của tôi) (fully loaded) Dual speed: High speed: Approx. 6-8 ft/min (1.8-2.4 m/của tôi) (fully loaded) / Low speed: Approx. 1.5-2 ft/min (0.45-0.6 m/của tôi) (fully loaded)
Running speed (if there is a trolley)	Manual trolley: N/A Electric trolley: Approx. 30-60 ft/min (9-18 m/của tôi) (không bắt buộc)
Wire rope	Diameter: Typically 5/16 inch (8mm) Construction: 6×19 or 6×25 IWRC (Independent Wire Rope Core)
Trình độ công việc	Class 1C (FEM 1 giờ sáng) or M4 (ISO)
Safety Factor	≥ 5:1
Motor	Type: Induction motor powered. Protection: Typically IP54 for dust and splash protection. Insulation: Class F for high thermal rating. Power (approximate): Single-phase: ~0.5-0.75 HP (0.37-0.55 KW) Three-phase: ~0.5-0.75 HP (0.37-0.55 KW)
Braking system	Dual brake: A key safety device. 1. Electromagnetic disc brake (main brake): Power on to release, power off to brake. 2. Mechanical load brake (auxiliary/emergency brake): Normally closed, independent of the main brake, to prevent the load from accidentally falling.
Phương pháp kiểm soát	Standard: Pendant Station Optional: Electric hoist with wireless remote control
Limit device	Standard configuration: Mechanical up/down limit switch
Bảo vệ quá tải	Built-in: Mechanical or electronic overload limiter (usually set at 110% rated load)
Power supply	120V, 1 Phase, 60Hz 230V, 1 Phase, 60Hz 208-230V, 3 Phase, 60Hz 460V, 3 Phase, 60Hz (không bắt buộc) Other voltages can be customized on demand (such as 240V/50Hz, vân vân.)
Operating temperature	Standard: -20°C to +40°C (derating required at +40°C)
Ingress Protection (IP)	IP54
Headroom	Standard: The specific value depends on the model and lifting height Low headroom (không bắt buộc): Significant optimization to maximize space utilization.
Standard Specifications	Meets or exceeds ASME B30.16 (USA), CMAA 74, Nữ 9.755 and other related standards
Deadweight	Approx. 80 – 120 lbs (36 – 54 kg)

Why choose Weihua 2000 pound electric hoist?

• Brand reputation: Weihua is a world-renowned brand in the crane industry, with a reputation for product quality and reliability.

• Strict quality control: From raw materials to finished products, a strict quality management system is implemented.

• Professional technical support: Provide professional pre-sales consultation, installation guidance and after-sales service.

• Wide applicability: Rich configuration options meet the specific needs of different application scenarios.

• Excellent value for money: Providing reliable performance and advanced features at a competitive price.

Weihha 2000 lb electric hoist is your trusted partner for lifting tasks up to 907 kg. It combines Weihua’s manufacturing strength, dedication to safety and user-friendly design to bring you efficient, smooth and safe material handling experience. Whether it is used for daily workshop operations, equipment maintenance or production line assembly, this electric hoist can provide excellent performance and lasting reliability.
